5. Scraping of pipe surface
• Turn the tool clockwise around the end of the pipe by the roller handle (1).
• Turn it steadily until the pipe surface is scraped up to the mark (Figure 4).
Figure 4
CAUTION
Danger of injury from rotating tool!
Do not reach into the working area of the scraper tool.
NOTICE
Do not push the tool in the direction of the axis of the pipe whilst scraping!
• The swarf is to be removed manually.
6. Disassembly of the scraper tool
• For disassembling of the scraping tool FWSG 63 turn the twist grip knob (2)
anti-clockwise.
• Pull the scraper tool off the pipe end.
• After use, store the tool in the transport box.
