PARTS CATALOG
CCW06B10B CCW08B10B
FIgure 901
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 68000464 41502-000051 - Base ALL 1
5 68000468 41508-000039 - Cabinet ALL 1
7 68000470 41503-000027 - Propeller Fan ALL 1
8 68000491 22001-000502 - Fan Motor ALL 1
10 68000472 41504-000207 - Vortex Shell ALL 1
12 68000473 42004-000142 - Centrifugal Fan ALL 1
14 68000475 41505-000282 - Electrical Box ALL 1
15 68000009 10303-100042 - Compressor
Capacitor
CCW06B10B 1
15 68000025 10303-100046 - Compressor
Capacitor
CCW08B10B 1
16 68000477 41505-000280 - Electrical Box Cover ALL 1
17 68000065 41214-000877 - Main pcb supporter ALL 1
18 68000462 31502-000041 - Main pcb ALL 1
19 68000040 10502-100032 - Transformer ALL 1
20 68000315 31502-000027 - Display pcb ALL 1
21 68000120 41507-000032 - Control Box panel ALL 1
22 68000479 41507-000019 - Front Panel ALL 1
23 68000480 41507-000115 - Leading Flow Circle ALL 1
24 68000481 41507-000091 - Louver ALL 1
25 68000482 41507-000070 - Louver Connecter ALL 1
26 68000167 41507-000106 - swing rod ALL 1
27 68000014 41507-000135 - Air Filter ALL 1
29 68000020 22007-000068 - Power Supply Cord ALL 1
30 68000036 22013-000936 - Remote Controller ALL 1
31 68000463 10104-100060 - Sensor ALL 1
33 68000484 41509-000063 - Adjustable shade
assembly
ALL 1
34 68000487 A1502-000018 - Top cover ALL 1
35 68000022 41509-000021 - Up Adjustable
shade rail
ALL 1
36 68000039 32001-000143 - wifi module ALL 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
