36 PB
PARTS CATALOG
CCF05B10A CCF06B10A CCF08B10A
FIgure 902
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 68000499 Base ALL 1
5 68000012 Cabinet ALL 1
7 68000018 Propeller Fan ALL 1
8 68000011 Fan Motor ALL 1
8 68000494 Fan Motor ALL 1
9 68000053 Back Partition Plate ALL 1
10 68000505 Middle Vortex Shell ALL 1
11 68000503 Up Vortex Shell ALL 1
12 68000473 Centrifugal Fan CCF05B10A 1
12 68000010 Centrifugal Fan CCF06B10A 1
12 68000016 Centrifugal Fan CCF08B10A 1
14 68000576 Electrical Box Assy ALL 1
14.1 68000009 Compressor Capacitor ALL 1
14.2 68000462 Main Pcb ALL 1
14.3 68000040 Transformer ALL 1
15 68000315 Display Pcb ALL 1
16 68000120 Control Box Panel ALL 1
21 68000575 Front Panel Assy ALL 1
27 68000014 Air Filter ALL 1
28 68000504 Down Vortex Shell ALL 1
29 68000020 Power Supply Cord ALL 1
30 68000495 Remote Controoller ALL 1
31 68000463 Sensor ALL 1
49 68000577 Installation Kit ALL 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
