38 PB
PARTS CATALOG
CCF10B10A CCF12B10A
FIgure 903
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 68000160 Front Panel Assembly ALL 1
1.6 68000027 Air Filter ALL 1
2 68000164 Electrical Box Assembly ALL 1
2.1 68000496 Main Pcb ALL 1
2.1 68000035 Power Supply Cord ALL 1
2.5 68000025 Capacitor ALL 1
2.7 68000040 Transformer ALL 1
4 68000502 Middle Vortex Shell ALL 1
5 68000512 Up Vortex Shell ALL 1
8 68000176 Cabinet ALL 1
12 68000032 Propeller Fan ALL 1
13 68000506 Back Surround Plate CCF10B10A 1
13 68000180 Back Surround Plate CCF12B10A 1
14 68000033 Fan Motor ALL 1
15 68000034 Centrifugal Fan ALL 1
16 68000501 Down Vortex Shell ALL 1
18 68000500 Base ALL 1
19 68000031 Sensor ALL 1
20 68000029 Display Pcb ALL 1
24 68000039 Wifi ALL 1
35 68000578 Installation Kit ALL 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
