9
Window seal
sponge
Sash lock
5.Extend the side accordion panels out against
the window frame as shown.
6.Drive 1/2” locking screws through frame holes,
and drive one 3/4” screw through top rail into
window sash as shown.
7.To secure lower sash in place, attach right angle
sash lock with 3/4” screws as shown.
8.Cut foam seal and insert in the space between
the upper and lower sashes as shown.
A storm window frame will not allow the air conditioner to tilt properly which in turn will keep it from draining
properly. To adjust for this, attach a board or piece of wood to the sill. The board or wood piece should have
a depth of at least 1/2”. Make sure the board or piece of wood is approximately 1/2” higher than the storm
window frame. This will allow the air conditioner to tilt enough for proper drainage.
16£¢MIN
SASH
1/2£¢MIN
Storm Window Frame
or Obstruction
1/2£¢MIN
Storm Window Frame or Obstruction
16£¢MIN
SASH
1/2£¢MIN
