Have the following tools available for installation:
* Screwdriver (Slotted and Phillips) * Ruler
* Knife * Hammer
* Pencil * Level
Installation Kit Contents
11
Type F:2EA
(SILL SUPPORT)
Type G:2EA
(BOLT)
Type C:5EA
(SCREW)
Type A:13EA
(SCREW)
Type D:2EA
(NUT)
10mm
16mm
Type H:1EA
(FOAM-STRIP)
Type K:2EA
(FRAME-GUIDE)
Type N:1EA
(DRAIN JOINT PIPE)
Type M:1EA
(FOAM-PE)
Type L:1EA
(WINDOWLOCKINGBRACKET)
16mm
Type B:3EA
(SCREW)
Type E:2EA
(FRAME CURTAIN)
10mm
