85 PB
COMPONENTS TESTING
Outdoor Unit - Main PCB ID
FSHSR09B1B, FSHSR12B1B
Reactor
L2
L1/N
SI
Basepan Heat
Reversing Valve
Outdoor Fan
White Connector
CN 907
Compressor
Discharge
Temp Sensor
Black Connector
CN 905
Condensor Coil
Temp Sensor
Yellow Connector
CN 904
Outdoor Ambient
Temp Sensor
Fuse
Compressor Out
(UVW)
