DIMENSIONS
Unit : inch (mm)
OUTDOOR UNIT
Drain hose length : 26-3/8 inch (670 mm)
INDOOR UNIT
39-1/4 (998)
9 (228)
12-5/8 (320)
22010.11.02
11-13/32 (290) 31-3/32 (790)
21-1/4 (540)
24-13/32 (620)
