Friedrich MS24Y3F - Page 27

Typical
Vert-I-Pak
®
installation
ACCESS DOOR OR PANEL TO
CLOSET CAN BE INSTALLED
FROM 3 SIDES
A
CC
E
SS
D
OO
R
O
R PAN
C
L
OS
ET
C
AN BE IN
S
T
A
FROM
3
SIDE
S
Ex
te
ri
o
r W
a
l
l
Fle
xi
ble
D
uct
w
o
r
k
Rigi
d
Ductwor
k
VPAWP1-8
/
1-14 Wall Plenu
m
Ple
n
u
m Divi
de
r
VPDP1
d
rain pan
b
eneat
h
u
nit is require
d
on a
ll
VEA
/
VHA24 units. Drain
p
an
must
b
e insta
ll
e
d
prior to
c
h
ass
i
s
in
sta
ll
at
i
o
n
Chassis is shi
pp
ed
wi
th
vi
b
r
at
i
o
n
isolato
r
s
in
stalled
3
"
Clea
r
a
n
ce
o
n
all
th
r
ee
s
i
des
minim
u
m
for
se
rvi
ce
a
n
d
in
stallat
i
on
O
ptional Plat
f
orm
Fie
ld
-supp
l
ie
d
Filter
(
25" x 20"
)
58"
29"
O
p
tional

eld
i
nsta
ll
e
d
d
rain
p
an
(
re
f
er to local codes
)
V
PRG4 A
ccess
P
a
n
el
&
Return Air Filter Grill
e
P
o
w
er
D
i
sco
nn
ect
SINGLE PACKAGE VERTICAL AIR CONDITIONERS
OPTIONAL ACCESSORIES
ARCHITECTURAL LOUVER
VPAL2 and VPSC2
Extruded aluminum grille that attaches
to the outdoor section of the wall plenum.
Takes in fresh air and returns condensed
air. VPSC2 can be ordered in custom
colors.
DIMENSIONS: 25 9/16" W x 31 1/16" H
WALL PLENUM
VPAWP1-8, VPAWP1-14
Two-part sleeve that telescopes in and out.
Sits inside the exterior wall penetration.
VPAWP1-8 telescopes from 5 1/2”–8”
VPAWP1-14 telescopes from 8”–14”
DIMENSIONS: 24 1/8” W x 30 3/8” H
CUTOUT DIMENSIONS: 24 5/8” W
x 30 7/8” H
FIRST COMPANY SLEEVE ADAPTER
VPASA1
Single piece, welded adapter allows retro-
fi t into existing First Company SPXR-series
single package vertical unit wall sleeve
and louver. Easy connection to Friedrich
chassis.
RETURN AIR GRILLE/
ACCESS PANEL
VPRG4
Hinged panel allows access to unit and
return air fi lter. A fi eld-supplied fi lter (25"
x 20") should be mounted on the inside
the grille. Panel can be mounted with re-
turn air openings high or low on the door
for optimum sound attenuation.
DIMENSIONS: 29" W x 58" H
CUTOUT DIMENSIONS: 27" W x 55 3/4" H
SINGLE STAGE THERMOSTAT
RT6
Single stage, wall-mounted digital ther-
mostat with two fan speeds and backlight
for control of Friedrich VERT-I-PAK.
WRT1
Wireless, single stage, wall-mounted
digital thermostat with two fan speeds
and backlight for control of Friedrich
VERT-I-PAK.
DRAIN PAN
VPDP1
For VEA/VHA24 models. May be installed
prior to chassis for easy installation/
removal.
VPASA1
27
