Multiple piping type _ 5
MULTI ZONEMULTI ZONE
Part 2 Product data_Outdoor units
Models : MR36TQY3JMA
Cooling
Heating
n Non ducted type indoor unit
Note :
1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 26.7°C (80°F) DB / 19.4°C (67°F) WB
- Outdoor Temperature 35°C (95°F) DB / 23.9°C (75°F) WB
Heating: - Indoor Temperature 21.1°C (70°F) DB / 15.6°C (60°F) WB
- Outdoor Temperature 8.3°C (47°F) DB / 6.1°C (43°F) WB
Piping Length - Interconnecting Piping Length 7.6m (25ft)
- Level Difference of Zero
2. Wiring cable size must comply with the applicable local and national codes.
3. The specification may be subject to change without prior notice for purpose of
improvement.
4. Maximum sum of connected indoor units capacity is 48 kBtu/h.
5. At least two indoor units should be connected.
Combination of
Indoor Unit (kBtu/h Class)
Room Capacity
Total Capacity
Input(W)
EER SEER
Min Rated Max
UNIT UNIT-A UNIT-B UNIT-C UNIT-D Total
UNIT-A
(Btu/h)
UNIT-B
(Btu/h)
UNIT-C
(Btu/h)
UNIT-D
(Btu/h)
Btu/h kW Btu/h kW Btu/h kW Min Rated Max
9 9 - - 18 9,000 9,000 - - 10,800 3.17 18,000 5.28 19,980 5.86 1,204 1,720 2,408 10.5 17.7
9 12 - - 21 9,000 12,000 - - 12,600 3.69 21,000 6.15 23,310 6.83 1,379 1,970 2,758 10.7 18.0
12 12 - - 24 12,000 12,000 - - 14,400 4.22 24,000 7.03 26,640 7.81 1,526 2,180 3,052 11.0 18.6
9 18 - - 27 9,000 18,000 - - 16,200 4.75 27,000 7.91 29,970 8.78 1,694 2,420 3,388 11.2 18.9
12 18 - - 30 12,000 18,000 - - 18,000 5.28 30,000 8.79 33,300 9.76 1,841 2,630 3,682 11.4 19.3
18 18 - - 36 16,000 16,000 - - 19,200 5.63 32,000 9.38 35,520 10.41 1,932 2,760 3,864 11.6 19.6
9 9 9 - 27 9,000 9,000 9,000 - 16,200 4.75 27,000 7.91 31,050 9.10 1,610 2,300 3,220 11.7 19.9
9 9 12 - 30 9,000 9,000 12,000 - 18,000 5.28 30,000 8.79 34,500 10.11 1,722 2,460 3,444 12.2 20.6
9 12 12 - 33 8,727 11,636 11,636 - 19,200 5.63 32,000 9.38 36,800 10.79 1,806 2,580 3,612 12.4 21.0
9 9 18 - 36 8,000 8,000 16,000 - 19,200 5.63 32,000 9.38 36,800 10.79 1,806 2,580 3,612 12.4 21.0
12 12 12 - 36 10,667 10,667 10,667 - 19,200 5.63 32,000 9.38 36,800 10.79 1,806 2,580 3,612 12.4 21.0
9 12 18 - 39 7,385 9,846 14,769 - 19,200 5.63 32,000 9.38 36,800 10.79 1,806 2,580 3,612 12.4 21.0
12 12 18 - 42 9,143 9,143 13,714 - 19,200 5.63 32,000 9.38 36,800 10.79 1,806 2,580 3,612 12.4 21.0
9 18 18 - 45 6,400 12,800 12,800 - 19,200 5.63 32,000 9.38 36,800 10.79 1,806 2,580 3,612 12.4 21.0
12 18 18 - 48 8,000 12,000 12,000 - 19,200 5.63 32,000 9.38 36,800 10.79 1,806 2,580 3,612 12.4 21.0
9 9 9 9 36 8,000 8,000 8,000 8,000 19,200 5.63 32,000 9.38 38,400 11.25 1,723 2,461 3,445 13.0 22.0
9 9 9 12 39 7,385 7,385 7,385 9,846 19,200 5.63 32,000 9.38 38,400 11.25 1,723 2,461 3,445 13.0 22.0
9 9 12 12 42 6,857 6,857 9,143 9,143 19,200 5.63 32,000 9.38 38,400 11.25 1,723 2,461 3,445 13.0 22.0
9 9 9 18 45 6,400 6,400 6,400 12,800 19,200 5.63 32,000 9.38 38,400 11.25 1,723 2,461 3,445 13.0 22.0
9 12 12 12 45 6,400 8,533 8,533 8,533 19,200 5.63 32,000 9.38 38,400 11.25 1,723 2,461 3,445 13.0 22.0
9 9 12 18 48 6,000 6,000 8,000 12,000 19,200 5.63 32,000 9.38 38,400 11.25 1,723 2,461 3,445 13.0 22.0
12 12 12 12 48 8,000 8,000 8,000 8,000 19,200 5.63 32,000 9.38 38,400 11.25 1,723 2,461 3,445 13.0 22.0
2 UNIT
3 UNIT
4 UNIT
2 UNIT
3 UNIT
4 UNIT
Combination of
Indoor Unit (kBtu/h Class)
Room Capacity
Total Capacity
Input(W)
COP HSPF
Min Rated Max
UNIT UNIT-A UNIT-B UNIT-C UNIT-D Total
UNIT-A
(Btu/h)
UNIT-B
(Btu/h)
UNIT-C
(Btu/h)
UNIT-D
(Btu/h)
Btu/h kW Btu/h kW Btu/h kW Min Rated Max
9 9 - - 18 9,900 9,900 - - 11,880 3.48 19,800 5.80 21,780 6.38 1,379 1,970 2,758 2.9 7.6
9 12 - - 21 9,900 13,200 - - 13,860 4.06 23,100 6.77 25,410 7.45 1,554 2,220 3,108 3.0 7.9
12 12 - - 24 13,200 13,200 - - 15,840 4.64 26,400 7.74 29,040 8.51 1,701 2,430 3,402 3.2 8.3
9 18 - - 27 9,900 19,800 - - 17,820 5.22 29,700 8.70 32,670 9.58 1,869 2,670 3,738 3.3 8.5
12 18 - - 30 13,200 19,800 - - 19,800 5.80 33,000 9.67 36,300 10.64 2,016 2,880 4,032 3.4 8.7
18 18 - - 36 18,000 18,000 - - 21,600 6.33 36,000 10.55 39,600 11.61 2,107 3,010 4,214 3.5 9.1
9 9 9 - 27 9,900 9,900 9,900 - 17,820 5.22 29,700 8.70 34,155 10.01 1,785 2,550 3,570 3.4 8.9
9 9 12 - 30 9,900 9,900 13,200 - 19,800 5.80 33,000 9.67 37,950 11.12 1,897 2,710 3,794 3.6 9.3
9 12 12 - 33 9,818 13,091 13,091 - 21,600 6.33 36,000 10.55 41,400 12.13 1,981 2,830 3,962 3.7 9.7
9 9 18 - 36 9,000 9,000 18,000 - 21,600 6.33 36,000 10.55 41,400 12.13 1,981 2,830 3,962 3.7 9.7
12 12 12 - 36 12,000 12,000 12,000 - 21,600 6.33 36,000 10.55 41,400 12.13 1,981 2,830 3,962 3.7 9.7
9 12 18 - 39 8,308 11,077 16,615 - 21,600 6.33 36,000 10.55 41,400 12.13 1,981 2,830 3,962 3.7 9.7
12 12 18 - 42 10,286 10,286 15,429 - 21,600 6.33 36,000 10.55 41,400 12.13 1,981 2,830 3,962 3.7 9.7
9 18 18 - 45 7,200 14,400 14,400 - 21,600 6.33 36,000 10.55 41,400 12.13 1,981 2,830 3,962 3.7 9.7
12 18 18 - 48 9,000 13,500 13,500 - 21,600 6.33 36,000 10.55 41,400 12.13 1,981 2,830 3,962 3.7 9.7
9 9 9 9 36 9,000 9,000 9,000 9,000 21,600 6.33 36,000 10.55 41,600 12.19 1,918 2,740 3,836 3.9 10.0
9 9 9 12 39 8,308 8,308 8,308 11,077 21,600 6.33 36,000 10.55 41,600 12.19 1,918 2,740 3,836 3.9 10.0
9 9 12 12 42 7,714 7,714 10,286 10,286 21,600 6.33 36,000 10.55 41,600 12.19 1,918 2,740 3,836 3.9 10.0
9 9 9 18 45 7,200 7,200 7,200 14,400 21,600 6.33 36,000 10.55 41,600 12.19 1,918 2,740 3,836 3.9 10.0
9 12 12 12 45 7,200 9,600 9,600 9,600 21,600 6.33 36,000 10.55 41,600 12.19 1,918 2,740 3,836 3.9 10.0
9 9 12 18 48 6,750 6,750 9,000 13,500 21,600 6.33 36,000 10.55 41,600 12.19 1,918 2,740 3,836 3.9 10.0
12 12 12 12 48 9,000 9,000 9,000 9,000 21,600 6.33 36,000 10.55 41,600 12.19 1,918 2,740 3,836 3.9 10.0
3. Combination table
