Frigelux RA445BE User Manual

35
8.Install the upper left hinge and upper
hinge cover in the manual bag and
right hinge cover
Installation of handles
This refrigerator is equipped with exterior handles, which are in the bag. Follow the instructions below
to install them.
1. Remove the two screws (8) using a Phillips screwdriver.
2. Pull out the handle (9) and fix it with the two screws (8).
3. Cover the two screws (8) with two caps (10), which are in the small bag with the handle.
Figure 1: Front view without handle.
Figure 2: Exploded view of handle installation.
Figure 3: Front view with handle.
7. TROUBLESHOOTING GUIDE
You can solve many common refrigerator problems easily, saving you the cost of a possible service
call. Try the suggestions below to see if you can solve the problem before calling for service.
