Installation & Owner’s Manual
6
261
213
>300
190
124
261
213
>300
190
124
110
157
NOTE
Four-way Cassette
(compact)
Four-Pipe
Two-Pipe
FIGURES 2
Drain side
545(Hook-location)
523(Hook-location)
575(Body)
647(Panel)
2800~2300(mm)
575(Body)
647(Panel)
Body
Central hole
Hook hole
Fixing hole
Drip tray
Drip tray
(Accessory)
Installation paper board
Ceiling
2800~2300(mm)
Water pipe joint
Connecting point of drain pipe
installation paper board
Ceiling
Water pipe joint Connecting point of drain pipe
Ground
Ground
Panel
Panel
Outlet
Outlet
600mm (ceiling hole)
600mm (ceiling hole)
Outlet
Outlet
Inlet
Inlet
(Unit: mm)
Tubing side
FIGURES 3
Fig.5-12
Fig.5-13
Fig.5-16
Fig.5-17
Fig.5-14
Fig.5-15
Fig.5-18
Before suspending installation, please connect the three-way
valve and its connected pipe to the main unit.
There are not three-way valve and the connected pipe be
attached inside. Yours may different from the gure as shows.
Note: the cover boards and the drip tray are accessories just for
the customers to choose.
Height of the front panel:
H
Type H(mm)
Four-way cassette 45
Four-way cassette
(compact)
50
