ENGLISH
INSTALLATION INSTRUCTIONS
STEP 2 - REVERSE DOOR (Optional) (Cont.)
4. Using a 3 mm hex key remove the hinge pin from the bottom hinge, and
then reinstall the hinge pin in the hole next to the hole from which it was
removed. Replace the two washers.
5. Remove the screw from the bottom of the cabinet and move it to the
matching hole on the opposite side.
6. Using the three hex-head screws removed earlier, reinstall the bottom
hinge on the opposite side.
Hinge Pin
Washers
Screw
Screw
Screws
To Next Page
