# = Fast-moving Parts 13 02/01
* = Non-Illustrated Parts
FRT21LRF, FRT21NRF & F44N21CE Publication No.
5995350419
SYSTEM
A = FRT21LRF (FRT21LRFD1)
B = FRT21LRF (FRT21LRFW1)
C = FRT21NRF (FRT21NRFD1)
D = FRT21NRF (FRT21NRFW1)
E = F44N21CE (F44N21CED2)
F = F44N21CE (F44N21CEW2)
POS. NO PART NO DESCRIPTION
1 # 218657100 A B C D E F Condenser
1* 5303017691 A B C D E F Spacer-tube
2 5308000296 A B C D E F Bracket,condenser mtg ,(4)
* 5308009617 A B C D E F Washer,ext tooth lock ,#10 ,grounding
4 # 218541000 A B C D E F Drier-filter,R134a System
5 # 218767600 A B C D E F Wiring Harness,control/divider
6 # 215257001 A B C D E F Wiring Harness,compressor
7 # 5316254901 A B C D E F Cord-electric power
8 5303001197 A B C D E F Cover-wiring
13 # 215076405 A B C D E F Heat Exchanger,suction line
14 # 5317842502 A B C D E F Heater-defrost
15 # 218765400 A B C D E F Evaporator
16 5308000110 A B C D E F Strap-evap/heater,aluminum ,(2)
17 5316651102 A B C D E F Insulator-evap,plastic
18 218773700 A B C D E F Insulation Block,RH
19 5303007287 A B C D E F Insulation Plug,RH
20 5308017227 A B C D E F Insulation Block,LH
21 # 5316269001 A B C D E F Thermostat-defrost
22 5308013663 A B C D E F Plate-compr mtg
23 218254500 A B C D E F Grommet-compr mtg,(4)
24 5308003633 A B C D E F Washer-compr mtg
25 5308003596 A B C D E F Clip-compressor mtg
26 215372500 A B C D E F Pan-defrost drain
26* 5308017610 A B C D E F Sound Tape,defrost pan
27 5303001348 A B C D E F Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C D E F Pan Retainer Kit,Service
29 # 5303917694 A B C D E F Compressor,R134a ,w/ovld & drier
30 # 218721100 A B C D E F Starter/Overload Assy
31 # 5303299560 A B C D E F Overload Protector
32 218740800 A B C D E F Clamp,elec cont mtg ,compressor
41 5308000039 A B C D E F Screw,hex washer head ,8-32CA x 0.500 ,srrt head
43 5303001199 A B C D E F Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B C D E F Clamp,nylon ,.625 ID
45 5303001343 A B C D E F Screw,hex washer head ,8-15A x 0.500
45 5303207328 A B C D E F Screw,hex washer head ,8-15A x 1.000 ,(2)
45* 5300141713 A B C D E F Screw,hex wshr hd ,8-32 x 0.625 ,spec
55 # 216236200 A B C D E F Capacitor-run,180-200 VAC ,15 microfarad
* # 5300189383 A B C D E F Hot Tube Repair Kit,Service
