3
Heating Element
page 12
Glass Trap
page 12
Self-Cleaning
Filter
page 12
Rinse Aid
Dispenser
page 11
Nozzle
Tub Gasket
page 14
Middle Spray Arm
pages 14
Lower Spray Arm
pages 14
Detergent Dispenser
page 10
Vent
pages
4,14
Top Rack
pages 7,8
Serial Label
(located on right
side of tub)
Bottom Rack
page 8
Your dishwasher cleans by spraying a mixture of hot water and detergent through the spray arms against
soiled surfaces. First, the dishwasher fills with water covering the filter area. Water is then pumped through
the filter and spray arms. Soil particles go down the drain as the water is pumped out and replaced with clean
water. The number of water fills will vary with the cycle being used.
Dishwasher Features
Silverware
Basket
page 9
Cup Shelves
pages 8
Overfill Protector
page 12
Appearance may vary from your model.
