3
Door Spring
Motor
Bottom Rack
page 6
Dishwasher Features
Serial label
(located on right
side of tub)
Your dishwasher, illustrated below, cleans by spraying a mixture of hot, clean water, and detergent against
the soiled surfaces of your dishes and tableware. Each cycle starts with a pre-drain. Next, the dishwasher
fills with water to a level even with the heating element. This water is constantly pumped through the rotating
spray arm and center wash tower and sprayed onto the dishes. Soiled water is pumped out and replaced
with clean water during a cycle. The number of water fills depends upon the cycle being used.
Leveling Legs
Heating Element
page 9
Normal Water
Fill Level
Float
page 10
Console
page 4
Lower Spray Arm
page 9
Tower Assembly
pages 6,9
Top Rack
page 6
To Next Page
