Frigidaire FFFU20F2VW - Door Reversal (Inside Controls); Tools and Preparation for Door Reversal

8
DOOR REMOVAL/REVERSAL
(UNITS WITH TEMPERATURE CONTROL INSIDE)

NOTE
The direction in which your appliance doors open (door swing) can be reversed,
from left to right or right to left, by moving the door hinges from one side to the
other. A qualified person should reverse the door swing.
IMPORTANT
Before you begin, turn the appliance temperature control to o and remove the
electrical power cord from the wall outlet. Remove any food from door shelves.
or
Tools Necessary:
Socket
Wrench Set
5/16"
(8mm)
Fixed
Wrench
Flathead
Screwdriver
and
or
Phillips
TM
Head or
#2 Square
Drive Head
Door Closer
#2 Phillips
Hinge
Screw
5/16"
(8mm)
Pan Head
MSX12
1. Unplug your freezer.
2. Remove the top hinge cover (see
Figure 1A).
3. Remove the 3 screws from the top
hinge using a Phillips™ screwdriver
or 5/16" wrench. Set the hinge and
screws aside (see Figure 1B).
Figure 1
A
B
