Frigidaire FFH17F8HW0 User Manual

54 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

All about

Servicing

Upright Freezers

With Standard And Electronic Controls

®

Publication #5995531505 January 2009

Electrolux Major Appliances; North America

250 Bobby Jones Expwy

Augusta, GA 30907

Table of Contents

Questions and Answers:

G
grahamangelAug 17, 2025
Why Frigidaire Freezer compressor does not run?
- S
  Stephen HoffmanAug 17, 2025
  If the Frigidaire Freezer compressor doesn't run, first ensure the freezer is properly plugged into the outlet. Then check the house fuse or circuit breaker and replace the fuse with a 15 amp time delay fuse or reset the circuit breaker if needed. Also, check if the freezer is plugged into a circuit that has a ground fault interrupt and use another circuit. Make sure that the temperature control is not in the "OFF" position, and set it to a desired temperature setting. Finally, verify if there is a power outage by checking house lights, and if necessary, call your local Electric Company.
R
Robin ThomasAug 20, 2025
Why is my Frigidaire FFH17F8HW0 running too much?
- F
  Frederick PalmerAug 20, 2025
  If your Frigidaire Freezer runs too much or too long, it might be due to several reasons. It's normal for the freezer to work harder under certain conditions and it takes about 24 hours to cool down completely. Warm food placed inside can also cause it to run longer until the desired temperature is reached. Try to open the door less often. Ensure the freezer door is properly closed and the gaskets are clean and in good condition, as leaks in the door seal will cause the freezer to run longer. If the temperature control is set too low, adjust it to a warmer setting and allow several hours for the temperature to stabilize.
T
Thomas BrewerAug 22, 2025
Why is my Frigidaire FFH17F8HW0 Freezer temperature too warm?
- F
  Frederick SmithAug 22, 2025
  If the interior temperature of your Frigidaire Freezer is too warm, try setting the temperature control to a colder setting and allow several hours for the temperature to stabilize. Remember that warm air entering the freezer causes it to run more, so open the door less often. If the freezer has recently been disconnected, allow it 24 hours to cool down completely. If the door may be slightly open, refer to the "Door will not close" section.
M
Mark BrooksAug 26, 2025
How to adjust temperature of Frigidaire FFH17F8HW0 Freezer when it's too cold?
- M
  mitchell57Aug 26, 2025
  If the interior temperature in your Frigidaire Freezer is too cold, adjust the temperature control to a warmer setting and allow several hours for the temperature to stabilize.
R
randolphbrendaAug 28, 2025
How to fix vibrating noise Frigidaire Freezer?
- P
  Paige HurstAug 28, 2025
  If you notice a vibrating or rattling noise coming from your Frigidaire Freezer, it could be due to a few reasons. First, check if the freezer is level and adjust it if it rocks on the floor. If the floor is uneven or weak, ensure it can adequately support the freezer and use wood or metal shims to level it. Also, make sure the freezer is not touching the wall; if it is, re-level or move it slightly.
C
Cynthia JohnsonAug 30, 2025
What to do if Frigidaire FFH17F8HW0 door will not close?
- K
  Kendra AndersonAug 30, 2025
  If your Frigidaire Freezer door won't close, make sure the unit is level. If it rocks on the floor when moved, adjust the leveling. Also, ensure the floor can adequately support the freezer. If the floor is uneven or weak, level the freezer by putting wood or metal shims under part of it.
K
kcrawfordSep 2, 2025
How to eliminate odors in Frigidaire FFH17F8HW0?
- C
  calvinhansonSep 2, 2025
  If you notice odors in your Frigidaire Freezer, clean the interior with a sponge, warm water, and baking soda. It may also be helpful to replace the air filter. Ensure that any foods with strong odors are tightly covered.
Z
Zachary StephensSep 5, 2025
Why is the external surface of my Frigidaire FFH17F8HW0 warm?
- S
  smithtiffanySep 5, 2025
  This is normal. While the compressor works to transfer heat from inside the Frigidaire Freezer cabinet, the external surface temperature may feel warm.
S
sanderskyleSep 7, 2025
Why is my Frigidaire FFH17F8HW0 making louder sounds than usual?
- B
  Brian WintersSep 7, 2025
  This is normal. When the surrounding noise level is low, you might hear the compressor running while it cools the interior of your Frigidaire Freezer.
C
Clayton CarterSep 12, 2025
Why is my Frigidaire Freezer louder when the compressor comes on?
- C
  Charles JohnsonSep 12, 2025
  This is normal. The sound will level off or disappear as your Frigidaire Freezer continues to run.

Frigidaire FFH17F8HW0 Specifications

General

Brand	Frigidaire
Model	FFH17F8HW0
Category	Freezer
Language	English

Summary

Section 1 Basic Information

Safe Servicing Practices

Guidelines for avoiding personal injury and property damage during appliance servicing.

Section 2 Installation Information

Location

Guidance on choosing an appropriate installation site for the freezer.

Leveling

Electrical Information

Instructions for proper electrical connection and safety precautions.

Section 3 Electronic Control

Electronic Temperature Control

Explanation of the electronic control panel and temperature settings.

Setting Selection

How to adjust the temperature settings using the control panel.

Service Diagnostic Mode

Procedure for entering and using the service diagnostic mode for troubleshooting.

Error Modes

Instructions for Programming EZ Set Controls

Section 4 Refrigeration

Safety Warnings

Crucial safety precautions for testing compressors and charging sealed systems.

Basic Components

Refrigerant Cycle

Low/High Side Leak or Undercharge

Identifies symptoms and causes of refrigerant leaks or undercharging.

Testing for Refrigerant Leaks

Compressor Replacement

Procedure for replacing the compressor, including contamination checks.

Installing a New Compressor

Detailed procedure for replacing the compressor unit in the refrigeration system.

Filter-Drier Installation

Evaporator and Suction Line Replacement

Equipment Needed for Evacuation & Recharging

Evacuating System

Steps for properly evacuating the refrigeration system to remove air and moisture.

Charging The System

Procedure for correctly charging the refrigeration system with refrigerant.

Final Leak Test

Verify Refrigerant Type In The System

R-134a Refrigeration Systems

Refrigerant Leaks

Discusses R-134a system susceptibility to leaks and their consequences.

Leak Detection

Inhalation Toxicity

Section 5 Component Teardown

Component Teardown

Overview of accessing and removing freezer components for service.

Evaporator Fan Assembly Removal

Defrost Heater Removal

Evaporator Removal

Compressor Area Components

Steps for accessing and removing components located in the compressor area.

Compressor Removal

Procedure for removing the main compressor unit.

Condenser Service

Section 6 Troubleshooting

Freezer compressor does not run.

Identifies causes and corrections for a non-operational freezer compressor.

Freezer runs too much or too long.

Diagnoses reasons for the freezer running excessively and provides solutions.

Vibrating or rattling noise.

Door will not close.

Identifies causes and solutions for a freezer door that does not close properly.

Compressor runs continuously, but freezer is not cold.

Addresses issues where the compressor runs but cooling is inadequate.

Freezer temperatures do not correspond with temperature control settings, but compressor operation is normal.

Discrepancies between settings and actual temperatures with normal compressor function.

Freezer does not automatically defrost.

Troubleshooting steps for issues with the automatic defrost cycle not engaging.

Section 7 Wiring Diagram

Wiring Diagram

Visual representation of the freezer's electrical connections and components.
