22
REVERSING DOOR
Reassembling the door
no. 6-7
no. 1-5
1 Lift the inner glass ring. Rotate it 180 degrees,
reinstall on outer door, lining up indicators - “LH”
for left-hand hinge or “RH” for right-hand hinge.
2 Rest the opening of the inner door at a 90 degree
angle on the supports for the hinge cutout cover.
Pivot the inner door down onto the outer door.
3 Replace indented head screws (no. 1-5) removed
earlier. Take care not to strip out the plastic holes.
4 Replace pan head screws (no. 6-7) removed earlier.
Take care not to strip out the plastic holes.
5 Locate new metal strike supplied with dryer
manuals. Grip new strike with pliers as shown
below. Firmly insert the strike so it is oriented
vertically.
