Frigidaire FFTR1614TW - Cabinet Leveling Procedures; Leveling with Front Rollers

6

NOTE
Raise the front of the refrigerator enough so
the doors close freely when opened halfway.
The refrigerator should slope ¼ inch to ½
inch from front-to-back. Then level the refrig-
erator from side-to-side.
To level the cabinet using the front
rollers:
1 Remove the toe grille.
Raise
9/16"
(14 mm)
Max
Figure 3
9/16"
(14 mm)
Max
Raise
Figure 2
or
3 Use adjustable wrench to adjust leveling
screws. Lower the leveling screws on each
sideclockwiseuntiltheycontacttheoor
(Figure 3). Do not raise the cabinet more
than
9
/
16
inch.
INSTALLATION
 2 Useaat-bladescrewdriveror⅜inch
socket wrench to raise or lower the front
rollers (Figure 2). Do not raise the cabinet
more than
9
/
16
inch.
