# = Fast-moving Parts 7 08/01
* = Non-Illustrated Parts
FGFL77A Publication No.
5995358156
A = FGFL77A (FGFL77ASB)
B = FGFL77A (FGFL77ASC)
C = FGFL77A (FGFL77ABB)
D = FGFL77A (FGFL77ABC)
E = FGFL77A (FGFL77AQB)
F = FGFL77A (FGFL77AQC)
POS. NO PART NO DESCRIPTION
1 316029416 A B C D E F Panel,main back
2 3131314 A B C D E F Shield,oven top
3 316230102 A B - - - - Panel,bodyside ,white ,RH
3 316230103 A B - - - - Panel,bodyside ,white ,LH
3 316230104 - - C D - - Panel,bodyside ,black ,RH
3 316230105 - - C D - - Panel,bodyside ,black ,LH
3 316230108 - - - - E F Panel,bodyside ,bisque ,RH
3 316230109 - - - - E F Panel,bodyside ,bisque ,LH
4 316201402 A B C D E F Burner Box
5 316129200 A B C D E F Screw,leveling ,plastic ,with stop
6 316067902 A B C D E F Rack,oven
7 316205000 A B C D E F Hinge,oven door ,RH
7A 316205001 A B C D E F Hinge,oven door ,LH
8 5303300701 A B C D E F Panel,oven bottom
9 316081900 A B C D E F Pan,broiler
10 316082000 A B C D E F Insert,broiler pan
12 # 316027701 A B C D E F Switch,oven light
13 316238800 A B C D E F Rod,light switch
14 # 316116400 A B C D E F Receptacle,oven light
15 5303013071 A B C D E F Bulb/Lamp,oven light
16 08011086 A B C D E F Lens,oven light ,glass
17 316087500 A B C D E F Retainer,lens
18 # 316213900 A B C D E F Latch,oven door
21 3014099 A B C D E F Spacer,bodyside
25A 5303288580 A B C D E F Shield,heat ,lower
28 3011813 A B C D E F Clip,wire ,bodyside
29 3051162 A B C D E F Glide,drawer ,front
30 316217700 A B C D E F Bracket,hinge ,RH ,main top
30A 316217701 A B C D E F Bracket,hinge ,LH ,main top
33 316232800 A B C D E F Shield,rear wall
35 316116600 A B C D E F Gasket,flue
36 316133002 A B C D E F Flue
37 # 316233900 A B C D E F Probe,oven temp
38 316051700 A B C D E F Shield,heat
39 3202006 A B C D E F Cord,electric power
40 3200836 A B C D E F Shield,heat baffle
40* 5303288570 A B C D E F Screw,hd shldr sqdr ,8-18 X 1/2 ,heat shield
41 316233400 A B C D E F Cover,hinge cutout ,RH
41A 316233500 A B C D E F Cover,hinge cutout ,LH
42 5303288578 A B C D E F Shield,bake burner
43 3131732 A B C D E F Screw,8-18 x 1.438 ,oven bottom
44 316246500 A B C D E F Spacer,oven door
49 316234200 A B C D E F Clip,maintop mtg ,(2)
53 5303288579 A B C D E F Shield,main front
53A 08067992 A B C D E F Shield,insulation ,front frame
53B 316211100 A B C D E F Bracket,air dam
55 316107800 A B C D E F Shield,flue
58A 316047708 A B C D E F Insulation,2" ,oven wrapper
58B 316218302 A B C D E F Insulation,oven back
58G 08067973 A B C D E F Insulation,main front
72 316234500 A B C D E F Cover,rod end ,light switch
88 316232700 A B C D E F Rod,auto latch
89 # 316135202 A B C D E F Motor,latch/lock
106 316026600 A B C D E F Bracket,motor mtg
107 316026701 A B C D E F Cover,fan
108# 316234601 A B C D E F Motor,fan
109 316136400 A B C D E F Blade,fan
110 316136500 A B C D E F Washer,fan motor
111 316136600 A B C D E F Nut,fan retainer
BODY
