7
Door stop is adjustable between 85 to 145 degrees.
Open door to provide access to screw.
2 Loosen screw.
3 Adjust door to desired location.
4 Rotate door stop until it makes contact with the
lower hinge.
Re-tighten screw.
Loosen or Remove
Screw
Open
Door
90
degrees
Bottom of Door
A
B
Ensure door stops in desired location before
resuming normal use.
:
Remove all food items from door bins on door
being adjusted.
2 Open doors to 90 degrees.
3 Loosen or remove screw.
NOTE
View shown is looking up at the bottom of the
refrigerator door.
NOTE
Adjustable hinge should only be used after doors have
been leveled with rollers.
