Frigidaire FGHB2844LE - Leveling the Freezer Drawer; Leveling Refrigerator and Doors

6


NOTE
DO NOT remove center screw from freezer drawer.
This is a factory adjustment.
:




 • Allfourcornersofthecabinetmustrestrmlyon
theoor.
 • Thesidesshouldtilt
1
/
4
inch (6 mm) from front to
back (to ensure that doors close and seal properly).
 • Doorsshouldalignwitheachotherandbelevel.
 Check gasket seal around top, bottom, and sides of
freezer drawer.
2 If gasket is not sealed, open drawer and slightly
loosen four (4) drawer screws (two (2) on each
side) to allow drawer to rotate.
3 Close drawer and recheck the seal on the gasket
(A). Open the drawer grabbing by the sides in the
center (B). Be careful not to rotate the drawer.
4 Tighten four (4) drawer screws.
 Recheck gasket seal.
 Installthetoegrillebyttingintoplace.
Pull Drawer Out
From Both Sides
Grab Drawer
At Center
Then
Push Against
Freezer Drawer
A B
Raise
Lower
Anti-tip
Leg
Door
Door
  You can raise or lower each door. use a 3/8 inch
socket wrench to turn the adjustment screws (1
per side).
: turn adjustment screw clockwise.
: turn adjustment screw counterclockwise.
3 Ensure both doors are bind-free with their seals
touching the cabinet on all four sides and that
cabinet is stable.
4 After unit is leveled, lower anti-tip leg until it
contactstheoor.



 Slightly open freezer drawer. Lift the toe grille and
gently pull forward (see illustration).
