FKFH21F7HWA Publication No: 5995514923
# Functional Parts
3 05/08
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216522312 Gasket-door, white
2 # 297213400 Lock Assy
2A 297213300 Clip, spring
5 297147700 Key, lock
9 297185900 Panel-inner door, frzr
11 297245402 Panel-outer door, white
13 297148400 Door Stop
18 297233800 Handle-door, white
* 240537301 Nut-anchor, door hdl screw
21A 297197500 Screw, door stop mtg, FH38-16X.750, P Twin
22 216970800 Bearing, hinge w/o'ring, top
22A 297006800 Bearing-hinge, btm, w/o'ring
26 216524200 Gasket, secondary
27 5303212828 Clip, panel mtg
27* 5304406520 Clip, panel mtg kit, (40)
32 5309950074 Valve, breather
48C 297225600 Bin-door, gallon
49 297187200 Bin-door, 2-liter, (5)
64 216403700 Plug-button, hole filler, door base
72 297186700 Shelf, tilt out, wire
73 216513900 End Cap, shelf, LH, tilt-out
74 216514000 End Cap, shelf, RH, tilt-out
79 218755404 Screw-set, 10-32 x 1.100
80 218755504 Screw-shoulder, #10 AB, handle mounting
93 5304460605 Screw, ph truss head, 8-18AB x 0.500
151# 297241900 Control-electronic, assy, white, 115V
To Next Page
