FKFH21F7HWA Publication No: 5995514923
# Functional Parts
5 05/08
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
3 216503100 Screen-drain
5 # 216325600 Fan Blade
6 297200900 Breaker Kit w/corners
7 297201100 Breaker Kit w/corners, lock catch
9 297200100 Breaker Kit w/corners, 32", top and bottom
13 216934100 Motor, fan, 115 V
14 297243800 Switch, light/lamp, plunger
15 216988100 Light Bulb/Lamp, long, blue tint, 40 W, 120V
16 216817601 Socket, light/lamp, 25 W
19 216204902 Gasket-evap cover
25 297099251 Cover-evaporator
26 216503300 Ramp, door closer
28 297240800 Hinge-bottom, stepped pin
29 216313501 Hose-drain
32 5308005500 Drain
34 297184400 Shield-light
35 216273000 Clip, drain hose
37 241611301 Trim-cabinet corner, white, (2)
38 297164300 Hinge-upper
40 297164400 Cover-hinge
41 297236200 Screw, tamper proof, 1/4-20 x 5/8
42 297119700 Shelf, wire, 16.69x27.88, white, (3)
42A 216458400 Shelf, 14.50x27.88
* 216502400 Grommet-shelf mtg
42C 297183702 Divider, blue, wire shelf
47 297192900 Baffle, air
50 216394050 Bracket, fan motor mount
59 297210900 Basket
59A 216486500 Stop-basket, (2)
59B 297209600 Basket
60 297013500 Slide, basket
63 216396900 Screw, leveling foot, plastic, adjustable
68 08009560 Glide-basket, (4)
69 5305878546 Bumper-basket, (2)
71A 297146800 Screw, 8-18AB x 0.470, EVAP PANEL
72 297198900 Grille/Kickplate, 32", white
79 3017666 Nut-insert
93 5304460605 Screw, ph truss head, 8-18AB x 0.500
93A 216629601 Screw, hex washer head, 10-16 x 0.500, tapping
169 216912401 Screw, hex washer head, 8-32 x 0.500, bracket fan mtr, (2)
* 297001704 Insulation, 24", drain tube
* 5303305324 Paint, touch-up, white
* 297089301 Energy Guide
* 297249900 Instructions, elect guide, Precision
To Next Page
