FKFH21F7HWA Publication No: 5995514923
# Functional Parts
7 05/08
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 5300083897 Condenser
2 5308000110 Strap-evap/heater, aluminum, (2)
4 216987500 Drier-filter
5 # 297237600 Harness-main
14 # 216730700 Heater-defrost
15 # 216997300 Evaporator
15A 297217900 Heat Exchanger, suct/cap tube
18 297078700 Insulator-evap, styrofoam
19 297078800 Insulator-evap, styrofoam
20 216872200 Thermostat, defrost
27 5308002681 Grommet, compressor
29 # 297223500 Compressor, w/o electricals
30 216954218 Controller
31A 297217000 Pan-drain
32 216954300 Clip, controller
35 297177200 Bolt, compressor
43B 297048400 Clip
55 216236200 Capacitor-run, 180-200 VAC, 15 microfarad
86 216036601 Screw, RWHD, 8-32A x 0.500, GX-CA
130 297244700 Support, evaporator mtg
* 216502500 Sleeve, suction line
* 240555002 Screw-#8-32 X 3/8
* 297014500 Plug-suction line
* # 297169900 Cord-power, flat
