4
Air Conditioner Features & Operating Instructions
Before you begin, thoroughly familiarize yourself with the control panel and remote
as shown below and all its functions, then follow the symbol for the functions you
desire. The unit can be controlled by the touch pad alone or with the remote.
ELECTRONIC CONTROL
Air Conditioner Features
2009 Electrolux Home Products, Inc. All rights reserved.
ADJUSTS
TEMPERATURE
OR TIME
DISPLAYS
TEMPERATURE/TIME
SETS FAN
SPEED
SETS MODE
TURNS UNIT
ON OR OFF
ACTIVATES TIMER
CHECK FILTER
RESET BUTTON
REMOTE TEMP
SENSING INDICATOR
(some models)
SLEEP MODE
w/DISPLAY &
REMOTE SENSING
BUTTON
FOR HEAT MODELS
Battery Size: AAA
Warning: Do not mix old and new batteries. Do not mix alkaline, standard
(carbon-zinc), or rechargeable (nickel-cadmium) batteries.
PRESS ON/OFF
BUTTON
DO THIS:
TO TURN UNIT ON: YOU WILL SEE:
NOTE
The following instructions represent the Touch Pad, the same instructions can be used for the Remote Control.
Operating Instructions
