Operating Instructions
Operating Instructions
(continued)
ADDITIONAL THINGS YOU SHOULD KNOW
Now that you have mastered the operating procedure, here are more features that you should become familiar with.
2009 Electrolux Home Products, Inc. All rights reserved.
Fresh Air Vent Control
The Fresh Air Vent allows the air conditioner to:
1. Recirculate inside air - Vent Closed (see Fig. 1)
2. Exchange air from the room - Vent Open (see Fig. 2)
Figure 1 (VENT CLOSED)
Figure 2 (VENT OPEN)
Air Directional Louvers
Air directional louvers control air flow direction. Your air conditioner has the louver
type described below.
Auger Type
The louvers will allow you to direct the air flow Up or Down and Left or Right
throughout the room as needed. Rotate the Auger Wheels until the desired
Left/Right direction is obtained. Pivot horizontal louvers until the desired
Up/Down direction is obtained.
AUGER WHEELS
(8-WAY)
