# = Fast-moving Parts 11 04/02
* = Non-Illustrated Parts
FRS26KW3A Publication No.
5995370185
A = FRS26KW3A (FRS26KW3AB3)
B = FRS26KW3A (FRS26KW3AB4)
C = FRS26KW3A (FRS26KW3AQ3)
D = FRS26KW3A (FRS26KW3AQ4)
E = FRS26KW3A (FRS26KW3AW3)
F = FRS26KW3A (FRS26KW3AW4)
POS. NO PART NO DESCRIPTION
5 # 5308000010 A B C D E F Fan Blade,red ,evaporator fan
8 5300157666 A B C D E F Bushing-motor mtg,(2)
9 5303292396 A B C D E F Bracket-motor mtg,front
13 # 240315803 A B C D E F Motor-evap fan
13* 215474201 A B C D E F Washer,"slinger" ,nylon ,evap fan shaft
14 5303292397 A B C D E F Bracket-motor mtg,rear
15 240436701 A B C D E F Light Bulb/Lamp,A-15 ,40 W ,120 V, miniature
16 218906801 A B C D E F Socket-light/lamp
17 240383302 A B C D E F Box-control,front
17* 240439901 A B C D E F Wiring Harness,controls
18 240360801 A B C D E F Knob,temp control
21 240375906 A B C D E F Control-temperature
21A 5304421768 A B C D E F Control-temperature
22 218660702 A B C D E F Tube-insulator
23 240375803 A - C - E - Control-defrost,adaptive timer, PC board
23 # 240545403 - B - D - F Control-defrost,adaptive timer, PC board
23* 5303001259 A B C D E F Screw-timer mtg,pan hd ,6-20 x 0.438, (2)
45 5303001343 A B C D E F Screw,hex washer head ,8-15A x 0.500
53 240369501 A B C D E F Box-control
81 5308016566 A B C D E F Screw,hex washer head, 8-15A x 0.625, low profile
115 240521101 A - C - E - Damper Assy,w/seal
115 240521103 - B - D - F Damper Assy,w/seal
115* 5304421593 A B C D E F Switch-micro, single pole, dble throw, damper assy
149 240331602 A B C D E F Shroud-fan orfice
* 3205266 A B C D E F Edge Protector,wiring harness
CONTROLS
