# = Fast-moving Parts 13 04/02
* = Non-Illustrated Parts
FRS26KW3A Publication No.
5995370185
A = FRS26KW3A (FRS26KW3AB3)
B = FRS26KW3A (FRS26KW3AB4)
C = FRS26KW3A (FRS26KW3AQ3)
D = FRS26KW3A (FRS26KW3AQ4)
E = FRS26KW3A (FRS26KW3AW3)
F = FRS26KW3A (FRS26KW3AW4)
POS. NO PART NO DESCRIPTION
1 240333603 A B C D E F Condenser
3 218679607 A B C D E F Block-evap coil,styrofoam ,(2)
4 # 218944001 A B C D E F Drier-filter,R134a System
6 240346402 A B C D E F Harness-wiring,machine compt
6* 240315901 A - C - E - Harness-wiring
6* 240449602 - B - D - F Harness-wiring
6* 240439901 A B C D E F Wiring Harness,controls
14 # 5303918253 A B C D E F Defrost Heater Kit
15 # 5303918216 A B C D E F Evaporator Kit
16 5308000110 A B C D E F Strap-evap/heater,aluminum ,(2)
21 5303918214 A B C D E F Thermostat-defrost,kit
22 240330003 A B C D E F Base-compressor
23 218513300 A B C D E F Grommet-compr mtg,(4)
25 240491501 A B C D E F Screw-compressor mtg,1/4-28 x 1.16, shlder,typ CF
26 240332602 A B C D E F Pan-defrost drain
29 # 5303918254 A B C D E F Compressor,w/electricals
30 # 218721119 A B C D E F Starter,PTC
32 218973501 A B C D E F Clamp,elec cont mtg, compressor
34 240405201 A B C D E F Grommet,rubber, black, cond tube/wire
41 218897001 A B C D E F Screw,hex washer head, 8-32 x 1/4
41* 5308000039 A B C D E F Screw,hex wshr hd, 8-32CA x 0.500, serr head
44 215174700 A B C D E F Clamp-service cord, strain relief, galv steel
45 5308016566 A B C D E F Screw, hex wshr hd, 8-15A x 0.625, low profile
55 # 218909901 A B C D E F Capacitor-run,220 VAC ,15 microfarad
57 240403601 A B C D E F Clip-wiring harness
58 215004600 A - C - E - Screw,hx wshr hd, 8-36 x 7/16, cond fan motor,(2)
58 240346801 - B - D - F Screw-cond fan mtr,hx wshr hd, 8-32 x 7/16,(3)
59 240315501 A B C D E F Shroud-cond fan
59* 240346701 A B C D E F Tape-foam seal,shroud
59* 240359401 A B C D E F Screw-fan shroud,(2)
59A 240346501 A B C D E F Bracket-support,cond mtr ,(3)
59B 240346601 A B C D E F Grommet-bracket,(3)
60 # 240334001 A - C - E - Motor,condenser fan
60 # 240397101 - B - D - F Motor-condenser fan
60* 240397201 - B - D - F Connector-shaft
61 # 240315401 A B C D E F Fan Blade,galv steel ,condenser fan
61A 215004700 A - C - E - Nut,speed
61A 218956701 - B - D - F Nut,speed ,fan blade
61B 215004800 A - C - E - Grommet-silencer
61B 218956801 - B - D - F Grommet-silencer
62 240429402 A B C D E F Trough-drain
70 218990801 A B C D E F Bracket-evap/cvr mtg
72 218397000 A B C D E F Button-handle mtg,dovetail
82 5304418225 A B C D E F Roller,compressor base ,rear ,(2)
83 5303316859 A B C D E F Rivet,flat head ,1/4 OD x 1-3/4, roller pin
84 5304421068 A B C D E F Tube-drain,lower
85 240346201 A B C D E F Tube-connector,suction
86 240409302 A B C D E F Spacer-cond tube,black
* # 5303918213 A B C D E F Heat Exchanger Kit,suction line
* # 5303918222 A B C D E F Hot Tube Repair Kit,Service
SYSTEM
