Frigidaire FRTE1622AW - Page 9

9
DOOR REVERSAL
7. a. Unscrew and remove the right
hinge sleeves, stoppers and lock
rings of both doors.
b. Take out the left door lock ring
from the accessory bag, and
install it to the left corners of
each door with the stoppers and
hinge sleeves.
c. Take out the hole plug and
hinge sleeve on the tops of each
door and install them on the
opposite side.
8. Lower the refrigerator door
in the open position onto the
bottom hinge.
B
C
B
A
A
B
A
9. a. Install the center hinge with
the hinge screws and hinge
plug on the left side. Tighten
the screws.
b. Insert the plug pins and the
center screw and cap on the
right side.
B
C
A
10. a. Locate the top hinge. Remove
the hinge pin from the right side
and place it on the left side.
b. Replace the upper hinge, cover
and hinge screws on the left side.
c. Replace the hinge cover on the
right side.
1
2
