4
Ignitor
Attachment
1. Remove the ignitor cap, spring assembly, bat-
tery and lock nut from ignitor. (See Fig. 1)
2. Insert the threaded section of the ignitor into
the U-shaped cut out of the ignitor mounting
bracket. (See Fig. 2)
3. Insert the threaded section of the ignitor
through the hole in the shelf and secure to
shelf using the lock nut.
(Use the ignitor
assembly diagrams to determine which
ignitor goes with which shelf.) Tighten
Securely. (See Fig. 3)
4. Re-insert the battery, positive side first, and
spring assembly and attach the ignitor cap.
(See Fig. 4)
5. Repeat above steps for second ignitor
on the Side Burner.
GL51 Ignitor Assembly
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Note: Prior to assembly remove protective film from stainless steel parts
Assembly requires: 4 tools and a Friend
Tools required:
1/4” socket wrench
1/2” socket wrench
adjustable wrench
scissors
Grill Assembly
Side Burner (Double Wire)
Left Shelf (Four Wire)
C
ap
Battery
Spring
Assembly
Locking
Nut
Cylinder
Mounting
Bracket
Keyhole
To Next Page
