# = Fast-moving Parts 15 10/01
* = Non-Illustrated Parts
PLHS267ZA Publication No.
5995360574
A = PLHS267ZA (PLHS267ZAB0)
B = PLHS267ZA (PLHS267ZAB1)
POS. NO PART NO DESCRIPTION
1 218976405 A B Tube-water inlet
1* 218976901 A B Tube-water inlet, inlet valve to ice maker
1* 218976903 A B Tube-water inlet,inlet valve to filter
1* 218976907 A B Tube-water inlet,valve to door
4 5304422012 A B Cover-module,black
8 5304422013 A B Module-dispenser
10 5304421626 A B Spring-torsion
14 240323927 A B Label-module cover,black
15 5304421616 A B Light Bulb/Lamp
16 215284900 A B Socket-light/lamp
17 5304421619 A B Screw
23 240323603 A B Drip Tray,black
24 5304425585 A B Actuator-water,black
24A 5304425584 A B Actuator-ice,black
30 5304421628 A B Door Assy-ice chute
30A 5304421624 A B Door center
30B 5304421625 A B Insulation-door
30C 5304421629 A B Door seal
35 5304421620 A B Damper-rotary
36 5304421824 A B Carrier
38 5304422632 A B PC Board,power
38A# 5304421617 A B Switch-micro,single pole ,double throw
38C 5304422633 A B PC Board,control
39 5304421627 A B Pin-hinge
41 5304421829 A B Spring-actuator
43 215296300 A B Screw,plask h/l ,#6 x 3/8
43* 240363401 A B Screw-#8-18 X 1/2,#6 hd plask
56 5304421830 A B Screw-micro switch,pan head
87 5304421622 A B Bearing Plate
87A 5304421621 A B Bearing Plate
88 5304421615 A B Shield-light
90 5304421831 A B Light pipe
91 5304421850 A B Light pipe,short
* 5303918256 A B Dispenser heater kit
DISPENSER
