# = Fast-moving Parts 19 10/01
* = Non-Illustrated Parts
PLHS267ZA Publication No.
5995360574
A = PLHS267ZA (PLHS267ZAB0)
B = PLHS267ZA (PLHS267ZAB1)
POS. NO PART NO DESCRIPTION
1 218976405 A B Tube-water inlet
1* 218976901 A B Tube-water inlet, inlet valve to ice maker
1* 218976903 A B Tube-water inlet, inlet valve to filter
1* 218976907 A B Tube-water inlet, valve to door
2 5304420650 A B Spring,shut-off arm
3 3206299 A B Label,ID plate
4 3206301 A B Gear
5 3206303 A B Plate-mounting
6 3206305 A B Screw-ground wire,8-32 x 0.250
7 # 3206306 A B Motor-ice maker
8 3206312 A B Spacer-hold switch
9 3206313 A B Cam
10 3206315 A B Clamp
11 # 3206319 A B Thermal Cutoff, ice maker, complete assy
12 # 240352601 A B Wiring Harness, ice maker, internal, with plug
13 # 3206322 A B Thermostat Assy,ice maker
14 5304420652 A B Screw,4 x 0.750 ,switch mtg.
15 # 3206324 A B Switch,(3)
16 5304420653 A B Support,phenolic
17 # 5303320545 A B Mold-ice maker,Radius Cube ,with heater
18 3206328 A B Ejector-ice
19 3206330 A B Bearing & Inlet
20 5304408581 A B Screw, 8-32 x 0.375
21 3206332 A B Ice Stripper
22 3206333 A B Shut-off Arm
23 5304408582 A B Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 A B Lever Arm
25 3206336 A B Screw, 8-18 x 0.562, lever arm/sprt
26 5304420654 A B Screw-thermo/sprt,4-24 x 0.375 ,(4)
27 3206338 A B Screw, 4-40 x 1.000, hold switch mtg, (2)
28 3206339 A B Screw-timing stop,4-40 x 0.375
29 3206323 A B Screw,4-24 x 0.750 ,(6)
30 3206341 A B Screw-timing adj,8-32 x 1.000
31 3206342 A B Insulator
32 3206343 A B Plate-valve switch
33 5304408583 A B Spring-timing adj
34 5304420655 A B Screw,plazscrew ,8-10 ,(3)
35 5304408585 A B Screw
36 3206347 A B Cover-ice maker
42 218515402 A B Clip,(2) ,tube mtg.
42* 5303001199 A B Clamp-wiring harness, strain relief, galv steel
45 5303001343 A B Screw,hex washer head ,8-15A x 0.500
46 5303001193 A B Clamp,.50 ID ,steel ,water tube
51 240387101 A B Tube-water,ice mold fill ,extension
55 # 240321801 A B Valve-water,triple solenoid
55* 218873001 A B • Cap-water valve
55*# 240508101 A B • Valve-water (Service), single solenoid
55*# 240508102 A B • Valve-water (Service), dual solenoid, 115 V
55* 240363601 A B Screw-shoulder
60 5303207328 A B Screw,hex washer head, 8-15A x 1.000, (2)
61 218721500 A B Bracket-leveling,ice maker
62 218737900 A B Screw-IM brkt mtg, hex washer head, 8-32D x 0.375
64 5303001549 A B Clamp,0.31 ID ,steel ,copper wtr line
* 218888001 A B Adapter-water supply, nut & sleeve, compression ftg
* 240352403 A B Ice Maker, Radius Cube, 115 V, no instl parts
ICE MAKER
