# = Fast-moving Parts 7 10/01
* = Non-Illustrated Parts
PLHS267ZA Publication No.
5995360574
A = PLHS267ZA (PLHS267ZAB0)
B = PLHS267ZA (PLHS267ZAB1)
POS. NO PART NO DESCRIPTION
10 240435902 A B Cover-air duct
10A 240475902 A B Cover-evap coil,lower
11 5303208309 A B Plug-hole,factory test
14 # 240413601 A B Switch-light/lamp
14A# 215486600 A B Switch-light/lamp
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 240457701 A B Plate-door closer
23 240402701 A B Screw-#10-32 x 1/4 flat hd
28 240335501 A B Bolt-roller addition, hex wshr hd,1/4-20 x 4.020, (2)
30 240419103 A B Bracket-lower hinge, ref
30A 240419104 A B Bracket-lower hinge
37 240337603 A B Trim-cabinet corner,black
38 240327202 A B Bracket-upper hinge
40 240327003 A B Cover-upper hinge,black
41 240358701 A B Grommet-shelf mtg,1.40" long
41* 240358801 A B Grommet-shelf mtg,.875" long
42 240315301 A B Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B Roller Assy,front ,(2)
45 241500301 A B Screw,hex washer head ,8-18AB x 0.500
47 240349401 A B Channel-shelf mtg,side ,(2)
58 218749600 A B Screw,#10 pan hd ,8-18 x .5
66 240504901 A B Cover-damper
66* 240518802 A B Pin-push,push-in ,plastic
66A 240505001 A B Damper-meat keeper
66B 240355901 A B Insulation-damper
72 240324406 A B Grille/Kickplate,black
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326104 A B Cover-access,w/ label
90 218249808 A B Seal-coil cover
91 240380101 A B Duct-ice maker
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
100 240423701 A B Support-crspr cover,(4)
100* 240350802 A B Support-crspr cover,(4)
150 240368701 A B Guide-control bulb
* 240396801 A B Clamp,tube/wiring ,nylon ,black/natural
* 240479601 A B Plug,button ,cab liner holes
* 5303305345 A B Paint,touch-up ,black
CABINET
