# = Fast-moving Parts 3 06/02
* = Non-Illustrated Parts
PLHS280ZA Publication No.
5995374534
FREEZER DOOR
POS. NO PART NO DESCRIPTION
1 # 240390606 Gasket-frzr door,black ,magnetic
4A 240334206 Bin-door,frzr-upper
4B 240351606 Bin-door
4C 240351706 Bin-door,frzr-dispenser
11 240451816 Panel-frzr door,stainless steel, complete assy
13A 240537106 Door Stop,black ,frzr
18 240536801 Handle-door, stainless steel, with insert
21A 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
22A 240328202 Bearing-hinge,closer
22C 240328404 Bearing-hinge,black ,upper
68 240467701 Chute-ice
79 218755402 Screw-set,10-32 x 0.375
80 218755503 Screw-shoulder,#10 AB ,handle mounting
96 240345506 Plug,door foam hole ,black
* 218490900 Cleaner,stainless steel
* 240323202 Harness-wiring,door
* 240352101 Connector-water,straight
* 240470401 Connector-amp
* 5303918256 Dispenser heater kit
