# = Fast-moving Parts 3 11/01
* = Non-Illustrated Parts
PLHT217TA Publication No.
5995360855
A = PLHT217TA (PLHT217TAB0)
B = PLHT217TA (PLHT217TAB1)
C = PLHT217TA (PLHT217TAB2)
D = PLHT217TA (PLHT217TAK0)
E = PLHT217TA (PLHT217TAK1)
F = PLHT217TA (PLHT217TAK2)
POS. NO PART NO DESCRIPTION
1 # 240390705 A - - D - - Gasket-frzr door, black, magnetic
1 # 240514611 - B C - E F Gasket-frzr door, black, magnetic
2 # 240390704 A - - D - - Gasket-refr door, black, magnetic
2 # 240514612 - B C - E F Gasket-refr door, black, magnetic
7 240338303 A B C D E F Door-dairy
11 240450317 A B C - - - Panel-frzr door, stainless steel, complete assy
11 240450318 - - - D E F Panel-frzr door,stainless steel, complete assy
12 240449704 A B C D E F Nameplate,black
13 240312405 A B C D E F Door Stop,black ,ref
13A 240312406 A B C D E F Door Stop,black ,frzr
15 240450419 A B C - - - Panel-refr door, stainless steel, complete assy
15 240450420 - - - D E F Panel-refr door, stainless steel, complete assy
18 240413701 A B C D E F Handle-door, stainless steel, with insert
21C 218252200 A B C D E F Screw,#8 truss hd ,10-32CA x 0.500
22 240311202 A B C D E F Bearing-hinge,black ,(8)
27A 240396102 A B C D E F Retainer,tall bottle
48 240338101 A B C D E F Bin-door,Pseudo ,bottom
48A 240430301 A B C D E F Bin-door,gallon
49 240337802 A B - D E - Bin-door,clear ,frzr
49 240495802 - - C - - F Bin-door,Pseudo ,frzr
79 218755402 A B C D E F Screw-set,10-32 x 0.375
80 218755501 A B C D E F Screw-shoulder,#10 AB ,handle mounting
96 240345506 A B C D E F Plug-foam hole,black
* 218490900 A B C D E F Cleaner,stainless steel
DOOR
