# = Fast-moving Parts 5 11/01
* = Non-Illustrated Parts
PLHT217TA Publication No.
5995360855
A = PLHT217TA (PLHT217TAB0)
B = PLHT217TA (PLHT217TAB1)
C = PLHT217TA (PLHT217TAB2)
D = PLHT217TA (PLHT217TAK0)
E = PLHT217TA (PLHT217TAK1)
F = PLHT217TA (PLHT217TAK2)
POS. NO PART NO DESCRIPTION
1 240355404 A B C D E F Cover-fan
5 # 5308000010 A B C D E F Fan Blade,red ,evaporator fan
8 5300157666 A B C D E F Bushing-motor mtg,(2)
9 5303292396 A B C D E F Bracket-motor mtg,front
10 240313603 A B C D E F Cover-evap coil
10* 240371303 A B C D E F Seal-coil cover
10*# 240385302 A B C D E F Wiring Harness,freezer section
11 5303208309 A B C D E F Plug-hole,factory test
13 # 240369701 A B C D E F Motor-evap fan
13* 218931001 A B C D E F Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B C D E F Bracket-motor mtg,rear
14* 240433201 A B C D E F Screw-8-18 x 3/8, hex washer head
15 215812200 A B C D E F Light Bulb/Lamp,25W
16 218906801 A B C D E F Socket-light/lamp
18 240345801 A B C D E F Support-evap cover,(2)
21C 218252200 A B C D E F Screw,#8 truss hd ,10-32CA x 0.500
22 215774918 A B C D E F Plug-button,black ,upr hinge holes
28 240335501 A B C D E F Bolt-roller addition, hex wshr hd, 1/4-20 x 4.020, (2), spec
30 240314003 A B C D E F Bracket-lower hinge
34 240311301 A B C D E F Washer,hinge ,nylon ,(2)
35 240313803 A B C D E F Bracket-ctr hinge,black
35A 240336801 A B C D E F Spacer-hinge,center
36 240516401 A B C D E F Pin-center hinge
37 240337603 A B C D E F Trim-cabinet corner,black
38 240313701 A B C D E F Bracket-upper hinge
40 240354404 A B C D E F Cover-upper hinge,black
41 5303001609 A B C D E F Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B C D E F Grommet,shelf mtg ,1.25" ,LH
42 240315301 A B C D E F Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B C D E F Roller Assy,front ,(2)
47 218233300 A B C D E F Channel-shelf mtg,side ,(2)
48 5303292395 A B C D E F Channel-shelf mtg,center
49 218362500 A B C D E F Screw,hex washer head ,8-18AB x 1.250
56 240516501 A B C D E F Pin-lower hinge
58 5303001343 A B C D E F Screw,hex washer head ,8-15A x 0.500
59 240442703 A B C D E F Screw-#10-32 X 3/4,black
72 240368203 A B C D E F Grille/Kickplate,black
74 240354301 A B C D E F Shield-light,frzr
81 5308016566 A B C D E F Screw, hex washer hd, 8-15A x 0.625, low profile
82 5304418225 A B C D E F Roller, compressor base ,rear ,(2)
83 5303316859 A B C D E F Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326115 A B C D E F Cover-access,w/label
89* 241500301 A B C D E F Screw,hex washer head ,8-18AB x 0.500
92 5303001479 A B C D E F Screw-hinge mtg,hex hd ,1/4-20 x 0.875
114# 240413601 A B C D E F Switch-light/lamp
* 218249806 A B C D E F Insulation,foam ,damper
* 218990901 A B C D E F Clip-wire
* 5303305345 A B C D E F Paint,touch-up ,black
CABINET
