# = Fast-moving Parts 9 11/01
* = Non-Illustrated Parts
PLHT217TA Publication No.
5995360855
A = PLHT217TA (PLHT217TAB0)
B = PLHT217TA (PLHT217TAB1)
C = PLHT217TA (PLHT217TAB2)
D = PLHT217TA (PLHT217TAK0)
E = PLHT217TA (PLHT217TAK1)
F = PLHT217TA (PLHT217TAK2)
POS. NO PART NO DESCRIPTION
1 240444401 A B C D E F Condenser,dynamic
4 # 218944001 A B C D E F Drier-filter,R134a System
6 240496101 A B C D E F Harness-wiring, machine compt
6* # 240375301 A B C D E F Wiring Harness, machine compt, w/service cord
6* # 240375501 A B C D E F Wiring Harness,control box
14 # 5303918247 A B C D E F Defrost Heater Kit
15 # 5303918250 A B C D E F Evaporator Kit
16 5308000110 A B C D E F Strap-evap/heater,aluminum ,(2)
17 240434002 A B C D E F Trough-drain
18 240362301 A B C D E F Insulation Block,RH
20 240362401 A B C D E F Insulation Block,LH
21 # 5303918202 A B C D E F Thermostat-defrost,kit
22 240330001 A B C D E F Plate-compr mtg
22* 218252200 A B C D E F Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B C D E F Grommet-compr mtg,(4)
25 240491501 A B C D E F Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF
26 240332602 A B C D E F Pan-defrost drain
29 5303918209 A - - D - - Compressor,w/electricals
29 5303918265 - B C - E F Compressor,w/electricals
30 # 218721112 A - - D - - Starter-PTC
30 # 218721120 - B C - E F Starter-PTC
32 218740800 A - - D - - Clamp, elec cont mtg, compressor
32 240493301 - B C - E F Clamp, elec cont mtg, compressor
34 240405201 A B C D E F Grommet, mounting, rubber, black, holds tube/wire
41 218897001 A B C D E F Screw, hex washer head, 8-32 x 1/4
41* 5308000039 A B C D E F Screw, hex washer hd, 8-32CA x 0.500, serrated head
44 5303001199 A B C D E F Clamp-wiring harness, strain relief, galv steel
45 5308016566 A B C D E F Screw,hex washer head, 8-15A x 0.625, low profile
55 # 218909901 A B C D E F Capacitor-run,220 VAC, 15 microfarad
57 240403601 A B C D E F Clip-wiring harness
58 215004600 A B C D E F Screw,hx serr wshr hd, 8-36 x 7/16, cond fan motor, (2)
59 240315501 A B C D E F Shroud-cond fan
59* 240346701 A B C D E F Tape-foam seal,shroud
59* 240359401 A B C D E F Screw-fan shroud,(2)
59A 240346501 A B C D E F Bracket-support,cond mtr ,(3)
59B 240346601 A B C D E F Grommet-bracket,(3)
60 # 240334001 A B C D E F Motor,condenser fan
61 # 240315401 A B C D E F Fan Blade,galv steel ,condenser fan
61A 215004700 A B C D E F Nut,speed
61B 215004800 A B C D E F Grommet-silencer
82 5304418225 A B C D E F Roller, compressor base, rear, (2)
83 5303316859 A B C D E F Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240359601 A B C D E F Tube-drain,lower
85 240346201 A - - D - - Tube-connector,suction
85 240493101 - B C - E F Tube-connector,suction
86 240409302 A B C D E F Spacer-cond tube,black
* 218843800 A B C D E F Screw,hex wshr hd ,8-15A x 0.500
* 240396801 A B C D E F Clamp,tube/wiring ,nylon ,black/natural
* # 5303918210 A B C D E F Heat Exchanger Kit,suction line
* 5304421289 A B C D E F Hot Tube Repair Kit,Service
SYSTEM
