Frigomatic BD35-BD50 Manual v1 PAGE 3
CHAPTER 1
THE FRIGOMATIC BD 12/24V REFRIGERATION SYSTEM
The "Frigomatic BD" system consists of the following components:
1) The condensing unit:
FM100, FM200 Capri 50 with Air cooled
K35F and K50F Keel cooled
W35F and W50F Pump water cooled
2) The thermostat
Fridge or Freezer mechanical thermostat
Optional:
Full range mechanical Air sensing thermostat
Digital thermostat
(contact Penguin at
sales@penguinfrigo.co.uk for separate manual)
3) The aluminum evaporator
Type F Plate evaporator can be bent to suit the box
(contact sales@penguinfrigo.co.uk for details on bending if required)
Type H Ice box
Type B Freezer box evaporator
4) The water pump and relay or ump interface (mod. Milano W only).
5) The keel cooler heat exchanger (mod. Milano K only)
