FRIGOGLASS Plus-500 - APPENDIX-1 DOOR OPTIONS; Door lock option; Door holder option

APPENDIX-1
DOOR OPTIONS
(door lock – door holder)
Door Lock
Rod holder
Bracket
Hex ocket
Self tapping Screws
s
head screw
& washer
Door holder
rod
Door Lock
In case of door lock opon:
Remove the two rivets and use new rivets to
place them to the opposite side of the door
lower profile as shown in the figures.
a. Remove the rod holder bracket by unscrewing
self-taping screws and install it on the opposite
side of the door profile.
In case of door holder opon:
b. Remove the door holder rod & washer by
opening Hex. socket head screw and install it
on the opposite side of the door profile as
shown in the figures.
c. Please connue with the STEP-11.
*Use the hand drill with 3.5mm drill bit
and the hex key.
B
efore
Aer
