FRIGOGLASS Super-9 - APPENDIX-2 FRONT GRID OPTIONS; Door Lock Option; Door Holder Option

APPENDIX-2
FRONT GRID OPTIONS
(door lock – door holder)
Door holder
bracket, base
plate & hex
socket screws
Door lock
Door lock
B
efore
Aer
Door holder
bracket, base
plate & hex
socket screws
In case of door lock opon:
Remove the rivet and use a new rivet
to place it to the opposite side of the
front grid as shown in the figures.
Remove the door holder bracket &
it’s base plate and install it on the
opposite side of the front grid as
shown in the figures.
In case of door holder opon:
*Use the hand drill with 3.5mm drill bit
and the hex key.
