NTC type probe temperature range -40°C to +105°C.
It is positioned on the evaporator.
A fault of the probe or of the analogue input of the board determines the
Probe 2 Faulty alarm.
Probe calibration parameter CA2.
Type of probe, parameter P0 (1=NTC).
The decimal point of the temperature is managed with parameter P1.
°C or °F setting parameter P2.
Evaporator probe function, parameter P3.
Minimum evaporator temperature during overcooling, parameter r6.
NTC type probe temperature range -40°C to +105°C.
Not available on the models set-up for the remote unit.
It is positioned on the condenser outlet tube.
A fault of the probe or of the analogue input of the board determines the
Probe 3 Faulty alarm.
Probe calibration parameter CA3.
Type of probe, parameter P0 (1=NTC).
The decimal point of the temperature is managed with parameter P1.
°C or °F setting parameter P2.
Condenser probe enabled by parameter P4 (1=environment/condenser
probe).
Condenser temperature above which the OVERHEAT.COND. alarm is
activated, parameter C6.
Condenser temperature above which the “Comp. Locked” locked compressor
alarm is activated, parameter C7.
Detects whether the door is closed or open during the equipment operation.
Its intervention determines the Door Open alarm.
The effect caused by the door microswitch is managed by parameter i0.
Door microswitch polarity parameter i1.
Door open alarm signal delay, parameter i2.
HACCP menu Door open alarm memorisation enable, parameter i4.
Activates defrosting with door opening duration longer than parameter i14.
The operation of the E2 and E8 heaters is managed by the K4 relay.
The models with temperature range 0-10°C have defrosting for compressor
stop, parameter d1 =2.
The E2 heater is equipped with KLIXSON thermostats (B2), connected in
series, that intervene when the working temperature > 70 °C.
The E8 heaters are connected together and managed as a single piece.
Interval between defrosts, parameter d0.
Type of defrost, parameter d1 (0=electrical; 1=hot gas 2=stop – models with
range 0-10°C).
Defrost end temperature, parameter d2.
Defrost duration, parameter d3.
Temperature display during defrost, parameter d6.
Dripping duration, parameter d7.
Defrost type, parameter d8: 0 at intervals; 3 adaptive; 4 in real time (only for
models equipped with “rtc” clock module).
Defrost activation in real time, parameters Hd1,2,3,4,5,6, with d8=4 (only for
versions with “rtc” clock module).
