The start-up and operation of the electronic board are guaranteed by the
12VDC power supply generated by the transformer.
The 12VDC power supply is also used to power the cell LED lights and glass
doors (optional).
Power supply voltage 230V with +/- 10% tolerance.
The power part of the board (K1/K2/K3/K4 relay) is powered directly at 230V.
Allows to connect the equipment for data download.
High pressure safety pressure switch installed on the water condensed
models. It intervenes at 29.5BAR and resets at 24.5BAR.
ATTENTION: the intervention of the safety pressure switch cuts-off the
main power supply of the equipment.
