8.9. Cell light replacement
1. Loosen the central screw closing the front panel using a
screwdriver.
2. Lift the front panel, being careful to secure it to the
rear body.
3. Remove the electric box by loosening the two locking
screws using a screwdriver.
4. Disconnect the light from the board.
5. Carefully remove the two clips holding the
protective glass.
6. Gently remove the light from the seat, being careful
not to drop it.
