FROMM
CH12-TI-FS250.EN10
Differences with F7:
1. When you push START the 3 beeps of the buzzer are much faster (150msec vs 1sec),
2. Password for un-block the parameters
To block the parameters press the 2 buttons of the top presser for approx. 5 seconds, (1) + (2)
To un-block parameters press the 2 buttons of the top presser for approx. 5 seconds, (1) + (2)
then this will appear on the displays
Left side : “B_L” (D_L)
Right side: “B_R” ( D_R )
Notice!
ATTENTION NOW YOU ARE IN A SPECIAL MODE
DO NOT PRESS STOP
DO NOT PRESS EMERGENCY
Input value T13 on the left side
Input value T14 on the right side
then PRESS STOP and you have un-blocked the parameters.
Important NOTE:
If you put program F8 in a board, in wich there was F7 or older releases
you have to enter the hidden parameter menu to input all the correct
values. See page 20 for the standard values
We advise after uploading a new programm to check all the parameters:
- F0 – F6,
- Speeds and turns,
- Parameters of the cycles
MASKED PARAMETERS
D_L
D_R
1
2
