EXPLANATION OF PICTOGRAMS
COMMAND PLATES
Fig. 7
Figure 7:
It is prohibited to pass by within the lifting equipment’s ray of action
Fig. 8
Figure 8:
Do not use bare flames and do not smoke
Fig. 9
Figure 9:
Don’t access the area while the machine is working
Fig. 10
Figure 10:
Don’t remove the SAFETY DEVICES
Fig. 11
Figure 11:
Don’t execute any work before taking off the voltage of the machine
Fig. 12
Figure 12:
Truck insertions
Fig. 13
Figure 13:
Lifting points
Fig. 14
Figure 14:
This identifies situations in which
THE SUPPLIER must be contacted
