LIGHTING INSTRUCTIONS
1. Locate the control and igniter panel. Make
sure the control knob is in the “OFF”
position. See Figure 7. Open the tank door
and open the tank valve all the way.
Figure 7
5.
Tighten threaded knob found on tank tray
(
Figure
6)
so that the LP can’t move from side
to side.
Figure 6
LOW
HIGH
CONTROL KNOB
2. Turn on the control knob to the “LOW”
position, then push in the igniter button.
You will hear a slight cliking sound. Once
The the flame is lit, turn the control knod to
the “ High” position. If the fire does not
light, turn the knob to the “ OFF” position
and wait five (5) minutes, before trying again.
3. To shut down the fire pit, trun the control
knob to the “OFF” position and trun off the
tank valve.
IGNITER BUTTON
9
