35 5TLT698 FLATWASHER, 1 1/8" 4
36 5TLT20 LOCKWASHER, 1 1/8" 4
37 5TLT18A LOCK NUT, 1 1/8" 4
38 5TLT13 AXLE 1 1/8" X 31 5/8" MODEL DH1376 4
5TLT133 AXLE 1 1/8" X 34 5/8" MODEL DH1380 4
5TLT14 AXLE 1 1/8" X 40 5/8" MODEL DH1396 4
5TLT141 AXLE 1 1/8" X 42 3/8" MODEL DH1396 4
39 5TLT892 HEX BOLT, 3/8" X 3", GR. 5 16
40 5TL12899 FLANGE LOCK NUT, 3/8" 16
41 5TL14996 SMV SIGN 1
42 5TL14997 SMV MOUNTING BRACKET 1
43 5TL14998 CARRIAGE BOLT, 5/16" X 1" GR. 2 2
44 5TL15198 LOCK NUT, 5/16" 4
45 5TL15212 ROUND HEAD MACHINE SCREW, 1/8" X 1/2", GR. 2 2
46 5TL15213 HEX NUT, 1/8" 2
47 5TL15189 ASSEMBLY MANUAL TUBE AND CAP 1
48 5TL15214 HEX BOLT, 5/16" X 1
1
/4", GR. 2 2
49 5TL15208 CAT. 2 TOP LINK PIN, 4 3/8" USABLE LENGTH 1
50 5TL15211 CAT. 2 BUSHING, 2 7/8" 1
51 5TL15207 CAT, 1 TOP LINK PIN, 4
3
/4" USABLE LENGTH 1
* M/S - Model Specific Parts Catalog 14
Parts List (cont’d)
Ref.# Part # Description Qty.
52 5TL15194 SAFETY DECAL SHEET(INCLUDES 4 DECALS) 1
53 5TL15638 SET OF LOWER HITCH BUSHINGS FOR IMATCH N/A
5TL15223 MODEL DH1376 DECAL(NOT SHOWN) 1
5TL15224 MODEL DH1380 DECAL(NOT SHOWN) 1
5TL15225 MODEL DH1396 DECAL(NOT SHOWN) 1
5TL15195 2 1/2” FRONTIER LOGO DECAL (NOT SHOWN) 3
5TL15193 DH13 OPERATOR’S MANUAL (NOT SHOWN) 1
5TL15240 4 1/2” RED REFLECTOR(NOT SHOWN) 2
5TL15199 9” RED REFLECTOR,Model DH1396(NOT SHOWN) 2
5TL15200 9” YELLOW REFLECTOR,Model DH1396(NOT SHOWN) 2
54 5TL9401 JAM NUT, 1 1/8" 4
55 5TLTMBT602 TRUNNION HOUSING, BEARING, & SNAP RING 8
