Frontier DH1380 User Manual

1 Specifications
The purpose of this manual is to assist you
in operating and maintaining your Disc
Harrow. Read it carefully. It furnishes infor-
mation and instructions that will help you
achieve years of dependable perfor-
mance.
These instructions have been compiled
from field experience and engineering
data. Some information may be general in
nature, due to unknown and varying oper-
ating conditions. However, through expe-
rience and these instructions, you should
be able to develop procedures suitable to
your particular situation.
The illustrations and data used in this
manual were current at the time of print-
ing. However, due to possible inline pro-
duction changes, your machine may vary
slightly in detail. We reserve the right to
redesign and change the machines as
may be necessary without notification.
Throughout this manual, references are
made to right and left direction. These are
determined by standing behind the tractor
facing the direction of forward travel.
GENERAL INFORMATION
SPECIFICATIONS
DH1376
DH1380
DH1396 DH1396
3-Point Hitch Category 1 and 2
(iMatch Compatible)
Category 1 and 2
(iMatch Compatible)
Category 1 and 2
(iMatch Compatible)
Category 1 and 2
(iMatch Compatible)
Working Width 76" 80" 96" 96"
Blade Spacing 9" 7.5" 9" 7.5"
Tractor HP (MAX) 75 HP 75 HP 75 HP 75 HP
Shipping Weight 1229 lbs. 1326 lbs. 1376 lbs. 1466 lbs.
Approximate
Operating Weight
1109 lbs. 1206 lbs. 1256 lbs. 1346 lbs.
Number of Blades 16 20 20 24
Blade Size 22" diameter 22" diameter 22" diameter 22" diameter
Blade Thickness 4mm(.157) 4mm(.157) 4mm(.157) 4mm(.157)
Blade Type 1. Notched (Front) /
Notched (Rear)
2. Smooth (Front) /
Smooth (Rear)
3. Notched (Front) /
Smooth (Rear)
1. Notched (Front) /
Notched (Rear)
2. Smooth (Front) /
Smooth (Rear)
3. Notched (Front) /
Smooth (Rear)
1. Notched (Front) /
Notched (Rear)
2. Smooth (Front) /
Smooth (Rear)
3. Notched (Front) /
Smooth (Rear)
1. Notched (Front) /
Notched (Rear)
2. Smooth (Front) /
Smooth (Rear)
3. Notched (Front) /
Smooth (Rear)
Frame Tubing 4” X 3" 4” X 3" 4” X 3" 4” X 3"
Gang Tubing 4” X 3" 4” X 3" 4” X 3" 4” X 3"
Bearing Hanger 2” X 4” steel tubing with 3/4
u-bolt
2” X 4” steel tubing with
3/4 u-bolt
2” X 4” steel tubing with
3/4 u-bolt
2” X 4” steel tubing with
3/4 u-bolt
Bearing Type Self aligning trunion
mount sealed ball
bearings
Self aligning trunion
mount sealed ball
bearings
Self aligning trunion
mount sealed
ball bearings
Self aligning trunion
mount sealed ball
bearings
Gang Axle 1 1/8" square 1 1/8" square 1 1/8" square 1 1/8" square
Front Gang Angles 9, 12, 15, 18 9, 12, 15, 18 9, 12, 15, 18 9, 12, 15, 18
Rear Gang Angles 9, 12, 15, 18 9, 12, 15, 18 9, 12, 15, 18 9, 12, 15, 18
Apprx. Assembly Time 15 Min. 15 Min. 15 Min. 15 Min.

Frontier DH1380 Specifications

General

Brand	Frontier
Model	DH1380
Category	Farm Equipment
Language	English
